Forging Technology
T132
Process: 1-Piece Forged Load: Single hub load of 750KG The actual load is set according to the model
Material: 6061-T6 aluminum alloy
Standard: JWL, VIA, Dot-T
Quick Details
Higher Test Standards

Place of Origin

Guangdong, China

Brand Name

HTian

PCD

127mm, 139.7mm, 165.1mm, 114.3mm, 120.65mm, 143.1mm, customize

ET

10mm, 15mm, 18mm, 20mm, 30mm, 35mm, 25mm, 0mm, customize

Warranty

2 years

Material

T6-6061alloy aluminum

Finishing

Machining/Polish/Brushing

Width

10/11/12/14/16

Design

Concave Design

Model Number

H132

Size20,22,24,26 inchProduct NameRacing wheel
Color36 colors available

CB

Customize

Quality

100% Test

Package

Hard Carton

PatentRing stiffener and double crimping structureTestImpact/Cornering/Radial Fatigue Test

Lead Time

25 days

Application

Off-road cars/SUV/Trucks/Trailers


HTian standard is a combination of years of HTian technical experience, the actual measurement of internal vehicles and the problems encountered by customers in actual use of different road conditions.


TestJWLPCTDOTHTian
Cornering Fatigue100,000 Cycles100,000 Cycles100,000 Cycles150,000 Cycles
Radial Fatigue500,000 Cycles500,000 Cycles500,000 Cycles800,000 Cycles
Impact test 13°230 MM230 MM230 MM255 MM
Impact test 30°///1000KG/255MM
Impact test 90°///1000KG/160MM
Radial Impact test 90°///1000KG/15MM+500,000 Cycles


DETAILS INTRODUCE
Solid Coating Color
Brushed Transparent Color
Macaron color
